Description:
|
Usage
FK series of presses are suitable for powder metallurgy, fine ceramics, magnetic and relevant industry that need powder to suppress.
Characteristics
(1) These series of presses have assimilated foreign powder compacting technology and designed by oneself, the quality has up to international advanced levels.
(2) The die of presses don't move when suppressing blank, adopt the method of upper and lower punch pressing compacting at the same time, therefore the homogeneity of compacting density of the products is good, and the qualification rate is high.
(3) In the course of operating, it can carry on the adjustment of packing and pressing.
(4) It is easy to load and unload for the die set.
(5) The speed of compacting products can be stepless changed.
(6) The presses manufacturing is high in precision, the size of compacting products consistency is good, and the weight too.
(7) All movements of the presses are all realized by mechanical drive, so it is stable and reliable in work.
(8) It can be increased by other functions according to customer's enquiry.
Technical Specification
Specification Type FK-30 FK-60
Max pressing force KN 30 60
Upper ram stroke mm 48 70
Max depth of fill mm 30 50
Strokes n/min 18-54 15-50
Hopper volume L 3 6
High of operation table mm 800 1000
Motor power KW 1.5 2.2
Machine Weight Kg 550 1000
Dimension (L*W*H) mm 420*540*1350 600*540*1900
|
